General use door

MOD. UNIVERSAL

TECHNICAL SPECIFICATIONS

Single or double leaf metal door for general uses (office, warehouse, wc, etc.)
Door leaf of SANDWICH type made from galvanized metal sheet and internal fulfillment of honey-comb panel, with internal reinforcement and two hinges.
Frame made of galvanized metal sheet, width 1,5ΜΜ with the hinges installed.
There are holes all around the frame for the installation and socket all around the frame for the installation of rubber gasket. The frame includes the same top and bottom part, in order to allow the left or right opening installation.
Lock made of steel with door handles and escutcheons according to DIN 18273 FS.
The doors are electrostatic painted in RAL 7035 (light grey) anti-scratch or any other color follow-ing an agreement. Further, there is a possibility for digital printing on the door through a big themeselection.
Following demand a panic bar can be placed on the doors, as well as a hydraulic reintroductionmechanism for the leaf.

STANDARDIZED DIMENSIONS

SINGLE LEAF Width cm: from 70 to 115 per 5cm. Height cm.: from 200 to 220 per 5cm.

DOUBLE LEAF Width cm: from 120 to 230 per 5cm. Height cm.: from 200 to 220 per 5cm.
